Shower mixer - Exposed set with shower system ½" - Article No. 631.20.410.xxx-AA

631.20.410.xxx-AA
Exposed set with shower system ½"

Description

rain shower head ½“, ø 240 mm
flow rate of the rain shower head 11 l/min at 3 bar
full metal body, 3 mm ultra-thin, with ball joint and anticalcareous system
supply pipe, diverter, wall bracket to connect the exposed shower mixer, spout projection 360-380 mm
fitting for hand shower adjustable in height and inclination
shower combination, metal hand shower with anticalcareous system and backflow preventer
flow rate hand shower 18 l/min at 3 bar
metal shower hose 1500 mm, both sides with turning cone
exposed shower mixer for supply pipe ½“
2 ceramic internal upper parts ½"
discharge ¾”
concealed S-connections ½" x ¾”

Consisting of:
649.13.844.xxx | Rain shower head ½", ø 240 mm
649.20.210.xxx | Supply pipe, diverter, wall bracket
630.13.700.xxx | Shower combination
631.20.210.xxx-AA | Exposed shower mixer ½“ for supply pipe

Finishes

Handle options

Specification drawing (mm)

631.20.410.xxx-AA Specification drawing mm

Technical Data - Download

Product data sheet
pdf 65 KB Download
CAD files (DXF)
zip 8.2 MB Download
